12 AL058-01

ILLUSTRATED
PARTS
BREAKDOWN
AL500HYLA


This list contains replaceable parts used in your heater. When ordering parts, follow the
instructions listed under Replacement Parts on page 9 of this manual.

QTY.
KEY
NO.
PART
NUMBER
DESCRIPTION
LP NG
1
NBY50-200A1
Burner
1 1
2
AL037-01
Lp Main Buner Injector
1
3
AL037-02
NG Main Buner Injector
1
4
AB31001
Gas Outlet Tube ASM
1 1
5
NV2020-1223
Control Valve
1 1
6
AL031-01
Washer
1 1
7
AL030-01
Control Valve Main Inlet Nut
1 1
8 ML031-03
Control Knob
1 1
9 ML083-02
Ignitor
1 1
10
AB31002
Safety Pilot Inlet Tube ASM
1
11
NDW0811-LP
LP Saftey Pilot Injector
1
12
NDW0811-NG
NG Saftey Pilot Injector
1 1
13
NDW-L600X4
Pilot ignition ASM
1 1
