PARTS
MODEL ML100TBAHR
This list contains replaceable parts for your heater. When ordering replacement parts, follow
the instructions listed under Replacement Parts on page 28 of this manual.
ITEM PART # DESCRIPTION QTY
1 **MB10007 Cabinet Assembly 1
2 MB09003 Lower Front Panel Assembly 1
3 **MB11005 Reector Unit 1
4 ML086-03 Glass 1
5 ML087-03 Upper Glass Retainer 1
6 ML088-03 Lower Glass Retainer 1
7 **ML069-02 Self Tapping Screw 12
8 161130-01 SIT Thermostat Valve Assembly 1
9 **ML111-02 Thermostat Valve Base/Bracket 1
10 **6170-5Z Nut 2
11 **845-4.8x60Z Screws 2
12 MB29003 Grill Guard 1
13 **ML079-01 Self Locking Screw 2
14 ML084-03 Middle Panel 1
15 **NRV81FI-8 Pressure Regulator 1
16 ML073-02 Ignitor Cable 1
17 161132-01 Mounting Bracket Assembly 1
18 **MB40037 Main Inlet Tube Assembly 1
19 **MB40049 ODS Line Assembly 1
20 **MB40050 Burner Inlet Tube Assembly 1
21 **NBB10-000M2 Burner 1
22 **ML101-01 Burner Connector 1
23 **ML091-10 Injector 1
24 **ML103-02 Left Burner Support Bracket 1
25 **ML129-02 Regulator Mounting Bracket 1
26 ND1308x800x7 ODS/Pilot Assembly 1
26-1 ND0803-8 Thermocouple 1
26-2 ND0807 Ignitor Electrode 1
27 **ML105-02 ODS Upper Deector 1
28 ML083-03 Ignitor Assembly 1
29 PL023-01 Connector 1
30 NR02-02 Hose/Regulator Assembly 1
PARTS AVAILABLE - NOT SHOWN
161607-01 Hardware Package 1
**Not a eld replacement part.
