PARTS
MODEL ML150TPA
This list contains replaceable parts for your heater. When ordering replacement parts, follow
the instructions listed under Replacement Parts on page 32 of this manual.
ITEM PART # DESCRIPTION QTY
1 MB10055 Cabinet Assembly 1
2 MB09002 Lower Front Panel 1
3 MB11003 Reector Unit 1
4 MB19004 Burner Assembly 1
5 SIT545-000-B Thermostat Valve Assembly 1
6 ML111-01A Thermostat Valve Base 1
7 845-4.8-60Z Self Tapping Screw 2
8 MB060-01 Mounting Bracket 1
9 MB40007 Thermostat Outlet Tube 1
10 ML096-01 4-way Connector 1
11 ML115-01 4-way Connector Bracket 1
12 ML116-01 4-way Connector Fixed Nut 1
13 ML073-01 Ignitor Cable 1
14 ND1808-800-9 ODS Pilot 1
14-1 ND0803-8 Thermocouple 1
14-2 ND0807 Ignitor Electrode 1
15 ML026-01 ODS Mounting Bracket 1
16 ML069-02 Self Tapping Screw 14
17 MB40029 ODS Gas Line Assembly 1
18 MB40030 Burner Gas Line Assembly A 1
19 MB40031 Burner Gas Line Assembly B 1
20 MB40032 Burner Gas Line Assembly C 1
21 ML090-02 Injector 3
22 MB40006 Main Inlet Tube Assembly 1
23 NRV81FI-10 Pressure Regulator 1
24 96-4Z Washer 2
25 ML079-01 Self Locking Screw 2
26 MB29002 Grill Guard 1
27 ML083-03 Ignitor 1
28 ML105-03 ODS Deector 1
PARTS AVAILABLE - NOT SHOWN
MB28001 Hardware Package 1
ML065-01 Thermostat Sensing Bulb Clip 2
