58 PRODIGIT
BIT ID BIT VALUE REMARK
bit 0 0 = Off, 1 = Triggered Over Power Protection (OPP)
bit 1 0 = Off, 1 = Triggered Over Temperature Protection (OTP)
bit 2 0 = Off, 1 = Triggered Over Voltage Protection (OVP)
bit 3 0 = Off, 1 = Triggered Over Current Protection (OCP)
TABLE 4-11 REGISTER of Protection Status
[STATe
：
] CCR {AUTOR2}
Command Syntax:
[STATe：] CCR {AUTOR2} {；NL}
Purpose: Set the CC MODE RANGE, forcing RANGE II operation if required.
Description: Swaps the unit between AUTO RANGE and RANGE II. AUTO RANGE
Will allow the unit to move to the more precise range at low currents,
While forcing the unit to remain in RANGE II keeps the range consistent
Regardless of the current.
[STATe
：
] POLAR {POSNEG}
Command Syntax:
[STATe：] POLAR {POSNEG} {；NL}
Purpose: Sets the polarity displayed by the voltage meter.
Description: The voltage read-out can be set to POS for positive, and NEG for
Negative polarity display.
[STATe
：
] START
Command Syntax:
[STATe：]START {；NL}
Purpose: Set for Load to begin the test.
Description: Begins the test, according to the TEST CONFIG(TCONFIG), the load
Module will start to test the items and parameters as stored.
[STATe
：
] STOP
Command Syntax:
[STATe：]STOP {；NL}
Purpose: Stops the test, if one is in progress.
4.6.4. SYSTEM functions allows the user to read the part number of the
Load modules and turn RS232 control ON and OFF. Commands are also
Available for storing and retrieving load set-ups saved in the memory of the
Mainframe. The mainframe has 150 separate memory locations. This is
Comprised of 15 memory BANKS with each bank having 10 STATES.
331XF 333XF 334XF/G 33401F/G
BANK(n) 15 15 15 15
STATE(m) 10 10 10 10
TOTAL STATE 150 150 150 150
