9
10.Make sure that all parts are properly tightened before you use the treadmill. Note: Extra hardware may
be included. Keep the included allen wrenches in a secure place. The large allen wrench is used to adjust the
walking belt (see page 16). To protect the floor or carpet, place a mat under the treadmill.
9. See step 3. Firmly tighten the 1” Bolts (63) and the 2”
Bolts (114).
Lower the Handrails (not shown) to the floor. Make sure
that the Frame (86) is centered between the
Handrails. Firmly tighten the 3” Bolts (61).
Raise the Handrails to the vertical position. Set the hand
weights (not shown) on the Weight Rack, with the lightest
weights in the center.
69
86
61
61
9
8. Attach the Weight Rack (107) to the Uprights (73, 108) as
shown with four 3/4” Screws (2).
8
73
108
107
2
2
