10
11. Make sure that all parts are properly tightened before you use the treadmill. Note: Extra hardware may
be included. Keep the included allen wrenches in a secure place; the large allen wrench is used to adjust the
walking belt (see page 17). To protect the floor or carpet, place a mat under the treadmill.
10. Remove the knob from the pin. Make sure that the collar
and the spring are on the pin as shown. Insert the pin
i
nto the Latch Housing (30), and tighten the knob back
onto the pin.
30
1
0
Knob
Pin
Collar
Spring
To Next Page
