8
9. Make sure that all parts are properly tightened before you use the exercise cycle. Note: After assembly is
completed, some extra parts may be left over. Place a mat beneath the exercise cycle to protect the floor.
8. Identify the Left Pedal (22), which is marked with an
“L.” Using an adjustable wrench, firmly tighten the
L
eft Pedal
c
ounterclockwise
i
nto the left arm of the
Crank (29). Tighten the Right Pedal (not shown)
clock-
w
ise
i
nto the right arm of the Crank.
I
mportant:
Tighten both Pedals as firmly as possible. After
using the exercise cycle for one week, retighten
the Pedals. For best performance, the Pedals must
be kept tightened.
Adjust the Left Pedal Strap (25) to the desired posi-
tion, and press the end of the Left Pedal Strap onto
the tab on the Left Pedal (22). Adjust the Right Pedal
Strap (not shown) in the same way.
8
29
25
Tab
22
To Next Page
