7
2.
Attach six Base Pads (125) to the bottom of the Base
(131) with six 1” Tek Screws (126). Note: Only four Base
Pads are shown.
With the help of another person, carefully tip the tread-
mill so that the Base Pads (125) are resting on the floor.
131
125
125
125
126
126
126
2
3
3. Attach a Wheel (139) to the right side of the Base (131)
with a Wheel Bolt (134) and a Wheel Nut (135) as shown.
Attach a Wheel (not shown) to the left side of the Base
(131) in the same way.
139
135
134
131
4. Attach the Latch Assembly (110) to the Left Upright
(111) with the two Latch Screws (109). Be careful not to
overtighten the Screws.
110
111
109
4
