24
K
ey No. Qty. Description Key No. Qty. Description
PART LIST—Model No. PFEL85907.0 R0709A
1
1 Frame
21Upright
31Console Bracket
41Console
51Bottle Holder
61Left Upper Body Leg
71Idler Wheel
81Left Upper Body Arm
91Right Upper Body Arm
10 2 Foam Grip
11 2 Upper Cap
12 1 Left Pedal
13 1 Right Pedal
14 2 Pedal Arm
15 2 Pedal Bracket
16 1 Pivot Axle
17 2 Inner Bushing Set
18 2 Outer Bushing Set
19 10 Upright Bushing
20 2 Large Axle Cover
21 2 Pedal Arm Axle
22 4 Axle Cover
23 2 Wheel Cover
24 1 Crank Assembly
25 1 Crank Arm
26 1 Left Pedal Disc
27 1 Right Pedal Disc
28 2 Pedal Disc Cover
29 2 Adjustment Pin
30 2 Spring
31 1 Left Adjustment Bracket
32 4 Large Snap Ring
33 2 39mm x 31mm Wave Washer
34 4 Adjustment Bushing
35 2 Pedal Arm Bracket
36 2 Adjustment Knob
37 2 Fender Washer
38 2 Crank Bearing
39 1 Crank Spacer
40 1 Crank Arm Spacer
41 2 Magnet
42 1 Left Front Shield
43 1 Right Front Shield
44 1 Left Shield
45 1 Right Shield
4
6 1 Belt
47 2 Foot
48 1 Left Frame Cover
49 1 Right Frame Cover
50 2 Wheel
51 1 Flywheel
52 1 Idler
53 1 C-magnet
54 1 Resistance Motor
55 1 Motor Bracket
56 1 Resistance Arm
57 1 Clamp
58 1 Reed Switch/Wire
59 1 Magnet Spacer
60 1 Key
61 1 Square Nut
62 1 Flange Screw
63 2 M10 x 41mm Shoulder Screw
64 1 Flywheel Bolt
65 1 C-magnet Bolt
66 1 Idler Bolt
67 1 Key Screw
68 1 Crank Arm Screw
69 4 Resistance Motor Bolt
70 4 Resistance Motor Nut
71 4 Motor Bracket Screw
72 1 Belt Adjustment Screw
73 2 M10 x 58mm Shoulder Bolt
74 2 M10 Locknut
75 6 M10 x 70mm Button Screw
76 4 M6 x 38mm Button Bolt
77 4 M6 Locknut
78 10 M10 Split Washer
79 4 M10 x 20mm Button Screw
80 6 M6 x 16mm Button Screw
81 4 M8 x 12mm Button Screw
82 3 M8 Locknut
83 7 M6 Star Washer
84 35 M4 x 16mm Screw
85 2 Flywheel Spacer
86 2 M8 Washer
87 2 31mm x 24mm Wave Washer
88 6 Wave Washer
89 6 M4 Washer
90 4 M6 Large Washer
