7
4. Identify the Right Upright (72) and the Right
Upright Spacer (74), which are marked with
stickers. Insert the Upright Wire (78) through the
Right Upright Spacer as shown.
See the inset drawing. Tie the wire tie in the
Right Upright (72) securely around the end of
the Upright Wire (78). With the help of a second
person, hold the Right Upright near the Base
(80). Then, pull the other end of the wire tie until
the Upright Wire is routed completely through
the Right Upright.
3. Attach a Base Wheel (81) with the 3/8" x 2" Bolt
(4) and the 3/8" Nut (8) that you removed in step
1. Do not overtighten the Nut; the Base
Wheel must turn freely.
Cut the tie off the Upright Wire (78).
78
Tie
4
8
3
81
80
78
72
74
78
4
Wire
Tie
72
78
Tie
2
. With the help of a second person, carefully tip
the treadmill onto its left side. Partially fold the
Frame (53) so that the treadmill is more stable;
do not fully fold the Frame yet.
Cut the tie securing the Upright Wire (78) to the
B
ase (80). Locate the tie in the indicated hole in
the Base, and use the tie to pull the Upright Wire
out of the hole.
Attach a Base Pad (79) to the Base (80) in the
location shown with a Base Pad Spacer (25) and
a 1" Tek Screw (56). Then, attach another Base
Pad (79) with only a 1" Tek Screw (56).
80
56
5
3
79
2
79
56
78
Tie
Hole
25
To Next Page
