15
14. Do not pinch any wires during this step.
Attach the Console Base Cover (85) to the
Console Base (84) with four #8 x 1/2" Screws
(14); start all four Screws, and then tighten
them. Do not overtighten the Screws.
14
85
14
14
84
13
13. Slide the Oval Grommet (75) onto the Upright
Wire (74), and press the Oval Grommet into the
Right Upright (73).
75
73
To Next Page
