CUTTING HEIGHT ADJUSTMENT
Mower cutting height adjustment is made by removing lynch pin from the top
of each castor stem (square or round) and corner support and moving the
spacers either above or below support tube as required for your selected
cutting height.
NOTE: Cutting height starts at 1”, with no spacers under the bushing.
Adjust the height using 3/8” and 1” spacers.
Be sure all adjustments are set the same.
Spacers (3/8” & 1”)
Bushing
