Progressive TD65-2 - Main Frame Assembly

MAIN FRAME - 15.5' & 12'
Rev. 2, JUNE 09
ITEM
PART #
DESCRIPTION
15.5' Serial No.
12' Serial No.
QTY
1
521870
MAIN FRAME
9651371 & ABOVE
0965-21295 & ABOVE
1
2
521358
RH WING
1
3
O.L.
1/4" - 28 90
°
GREASE FITTING
4
4
521356
1" X 21" WING PIN
2
5
O.L.
3/8" X 1 1/2" W/ LOCK, NUT, 2 FLAT
4
6
521325
WING LOCK FRAME MT BRKT
2
7
521322
4 POSITION HITCH
1
8
521048
SAFETY CHAIN
1
9
O.L.
3/8" X 1 1/4" W/ LOCK, NUT, FLAT
6
10
521324
IMPLEMENT JACK
1
11
528192
FRONT SHIELD MT C.V (B&D MODELS)
1
12
528196
FRONT SHIELD MT. NON C.V.(A&C MODELS)
1
13
O.L.
3/4" X 5"BOLT, NUT & LOCK
1
14
528190
INTERMEDIATE MOUNT (B&D MODELS)
1
15
521355
LH WING
1
16
O.L.
1/2" X 6" BOLT, LOCK, NUT
4
17
O.L.
3/8" X 1 1/4 BOLT WITH LOCKWASHER
4
18
521331
PULL ROPE 10'
1
19
521329
WING LOCK FRAME
1
20
521330
WING SAFETY LOCK
1
21
O.L.
3/8" X 1 1/4" W/FLATS, NUT, LOCK
2
22
521064
SAFETY SPRING
1
23
521332
PULL CHAIN 23 1/4"
1
24
521081
1" X 5 5/16" PIN - REAR CYLINDER
1
25
O.L.
1/2" X 1 3/4" BOLT, NUT
2
26
528198
FENDER BRACKET L.H.
1
27
521841
REAR DECK SAFETY
9765545 & ABOVE
9765-2342 & ABOVE
1
521763
REAR DECK SAFETY
9465276 TO 9765544
9465-2044 TO 9765-2341
1
521348
REAR DECK SAFETY
9165101 TO 9465275
9365-2010 TO 9365-2043
1
28
522301
REAR DECK PICK UP FRAME
9565588 & ABOVE
9865-2423 & ABOVE
1
521708
REAR DECK PICK UP FRAME
9165101 TO 9865587
9365-2010 TO 9865-2422
1
29
521349
REAR DECK LIFT ARM
2
30
521094
LIFT ARM PIVOT PIN -1" X 9 3/4"
2
31
O.L.
GREASE FITTING - STRAIGHT
20
32
528200
FENDER BRACKET R.H.
1
33
521321
MAIN FRAME
9165101 TO 9651371
9365-2010 TO 0965-21295
1
OL - Obtain Locally AR - As Required QTY - Total Number Required for Complete Machine
11
