PART # DESCRIPTION 15.5' Serial No. QTY. 12' Serial No. QTY.
1 O.L. 1/4 - 28 GREASE FITTING 9 7
2 521003 LEFT HAND NUT 9 7
3 521002 LEFT HAND LOCK WASHER (3PC/KIT) 3 KITS 3 KITS
4 521773 2HB 4.4 X 1 1/8" PULLEY (RED) (A,B,C MODELS) 9365276 & Above 9 9365-2044 & Above 7
521300 2HB 4.4 X 1 1/8" PULLEY (BLACK) 9165101 to 9365275 9 9265-2002 to 9365-2043 7
5 521790 5.95" OD X 1-1/8" HUB PULLEY (D MODELS) 9 7
6 521301 1" SHIM WASHER (9PC/KIT) 1 KIT 1 KIT
7 521302 TOP BEARING, STEEL SHIELD UP 9 7
6206ZC3
8 521700 SPINDLE HOUSING (RED) 9165176 & Above 9 7
521303 SPINDLE HOUSING (BLACK) N/A 9165101 to 9165175 N/A N/A
9 521304 BEARING SPACER TUBE 9 7
10 521701 BOTTOM BRG, STEEL SHIELD UP 9 7
6206LBZC3/2AS
11 521305 1" SHIM WASHER (9PC/KIT) 1 KIT 1 KIT
12 521306 DIRT SHIELD (3PC/KIT) 3 KITS 3 KITS
13 O.L. 1/4" SQ. X 1 11/16" KEY 9 7
14 521307 BLADE SPINDLE 9 7
MOWER BLADES KITS
15 522603 5/16" X 2 1/2" X 23" - O.E.M. 9/KIT
522604 5/16" X 2 1/2" X 23" - O.E.M. 7/KIT
522606 5/16" X 2 1/2" X 23" - LOW LIFT 9/KIT
522607 5/16" X 2 1/2" X 23" - LOW LIFT 7/KIT
522611 MULCHING BLADE 9/KIT
522612 MULCHING BLADE 7/KIT
522506 MULCH HOOP KIT 12' (TD65-2) 1
522507 MULCH HOOP KIT 15' (TD-65) 1
16 O.L. 1/2" X 1 3/4" BOLT, LOCKWASHER, NUT 24 20
17 O.L. 7/16" X 1 1/2" BOLT, LOCKWASHER,NUT 36 28
4.4" PULLEY
18 521776 COMPLETE SPINDLE ASSEMBLY(A,B,C MODELS) 9365276 & Above 9 9265-2044 & Above 7
521340 SPINDLE ASSEMBLY LESS PULLEY(ALL MODELS) 9365276 & Above 9 9265-2044 & Above 7
521702 COMPLETE SPINDLE ASSEMBLY 9365176 to 9365275 9 9265-2002 to 9365-2043 7
521309 COMPLETE SPINDLE ASSEMBLY N/A 9165101 to 9365175 N/A N/A
5.9" PULLEY
19 521792 COMPLETE SPINDLE ASSEMBLY(D MODELS) 9 7
