Progressive TD65-2 - Hydraulic Component Assembly

HYDRAULIC ASSEMBLY - 15.5' & 12'
Rev. 1, OCT 05
ITEM
PART #
DESCRIPTION
15.5' Serial No.
12' Serial No.
QTY
1
521345
1" X 2.938" PIN AND CLIPS
2
2
521814
SEAL KIT FOR 2 1/2" CYLINDER
9865588 & ABOVE
9865-2423 & ABOVE
-
521477
SEAL KIT FOR 2 1/2" CYLINDER
9165101 TO 9865587
9365-2010 TO 9865-2422
-
3
522300
2 1/2" HYDRAULIC CYLINDER
9865588 & ABOVE
9865-2423 & ABOVE
3
521333
2 1/2" HYDRAULIC CYLINDER
9165101 TO 9865587
9365-2010 TO 9865-2422
3
4
521336
90° 3/8" RESTRICTOR ( 0.035)
9465276 &ABOVE
9465-2044 & ABOVE
3
222015
RESTRICTOR KIT (W/ 31" HOSE - EXTRA)
9165101 TO 9465275
9365-2010 TO 9365-2043
2
5
521769
31" HYDRAULIC LINE
9465276 &ABOVE
9465-2044 & ABOVE
3
521339
26" HYDRAULIC LINE
9165101 TO 9465275
9365-2010 TO 9365-2043
3
6
521063
45 DEGREE SWIVEL STREET ELBOW
9465276 &ABOVE
9465-2044 & ABOVE
3
521347
45 DEGREE SWIVEL STREET ELBOW
9165101 TO 9465275
9365-2010 TO 9365-2043
3
7
521335
24" HYDRAULIC LINE
3
8
521081
1" X 5 1/4" PIN- REAR CYLINDER
1
9
521103
1" X 4 3/4" PIN - WING CYLINDER
2
10
521416
MALE BRANCH TEE
9465276 &ABOVE
9465-2044 & ABOVE
2
11
521770
3/8" TEE
9465276 &ABOVE
9465-2044 & ABOVE
2
12
521073
FLOW DIVIDER
1
222016
FLOW DIVIDER KIT
9165101 TO 9465275
9365-2010 TO 9365-2043
1
13
521334
110" HYDRAULIC LINE
2
14
521051
HYDRAULIC HOSE CLAMP
1
15
O.L.
3/8" LOCKNUT
1
16
521071
"U" BOLT, NUTS, AND LOCKS
2
17
222006
HOSE END - 1/2" (2PCS/KIT)
1 KIT
18
521342
1/2" NPT TO JIC ADAPTER
2
19
521077
LINE THROTTLE VALVE
2
20
521343
REDUCING BUSHING
1
21
521344
90 DEG. ELBOW, MALE TO MALE
1
22
521391
3/8" TO 1/2" MALE NIPPLE
1
23
521392
45 DEG STREET ELBOW
1
24
521341
3/8" STRAIGHT SWIVEL ADAPTER
1
25
521350
1" x 3.563" PIN
1
521067
1" X 6 1/2" PIN (REAR)
9165101 TO 9365175
- - -
1
OL - Obtain Locally AR - As Required QTY - Total Number Required for Complete Machine
REPLACED W/ KIT 222016
REPLACED WITH 222015
REPLACED WITH 222015
REPLACED WITH 222015
REPLACED WITH 222015
REPLACED WITH 222015
REPLACED WITH 222015
REPLACED WITH 222015
15
