Progressive TD65-2 - Page 51

WING LIFT - 15.5' & 12'
Rev. 1, OCT 05
ITEM
PART #
DESCRIPTION
15.5' Serial No.
12' Serial No.
QTY
1
O.L.
3/8" X 2" BOLT, LOCK, NUT
6
2
521337
1" X 6 1/4 DECK LIFT PIN - SHORT
9765545 & ABOVE
9765-2342 & ABOVE
6
521395
1" X 6 1/2 PIVOT PIN
9465276 TO 9765544
9465-2044 TO 9765-2341
6
521351
1" X 6 1/2 PIVOT PIN
9165101 TO 9465275
9365-2010 TO 9365-2043
6
3
O.L.
1/4" - 28 GREASE FITTING
20
4
521710
DECK SWIVEL TD65-2 (12' MOWER)
2
521357
DECK SWIVEL TD65 (15.5' MOWER)
2
5
521358
R.H. WING
1
521355
L.H. WING
1
6
521102
1/2" X 3 1/2" SPADE BOLT, 1/2" NUTS
2
7
521431
2" X 10" SPRING
2
8
521338
1 1/4" X 16 3/4" SWIVEL PIN
9465295 & ABOVE
9465-2044 & ABOVE
2
521097
1 1/4" X 17" SWIVEL PIN
9165101 TO 9465294
9365-2010 TO 9365-2043
2
9
O.L.
3/8" X 2 1/4" BOLT, NUT, LOCK
2
OL - Obtain Locally AR - As Required QTY - Total Number Required for Complete Machine
