Progressive TD65-2 - Page 57

TD65 & 65-2 - WHEEL ASSEMBLY
Rev. 2, JUNE 09
ITEM
PART #
DESCRIPTION
15.5' Serial No.
12' Serial No.
QTY
1
522320
SQUARE CASTOR COMP. +PARTS
9765545 & ABOVE
9765-2342 & ABOVE
4
2
521038
CLIP PIN - 2" SQUARE (5 PCS/KIT)
9765545 & ABOVE
9765-2342 & ABOVE
1 KIT
3
521040
SPACER -SQ 3/8 X 2 1/2 (6 PCS/KIT)
9765545 & ABOVE
9765-2342 & ABOVE
2 KITS
4
521039
SPACER - SQ 1" X 2 1/2 (6 PCS/KIT)
9765545 & ABOVE
9765-2342 & ABOVE
2 KITS
5
521748
HUB CAP
9165101 & ABOVE
9265-2002 & ABOVE
10
6
521752
COTTERPIN (6 PCS/KIT)
9165101 & ABOVE
9265-2002 & ABOVE
2 KITS
7
521747
HEX NUT - CASTELLATED (2 PCS/KIT)
9165101 & ABOVE
9265-2002 & ABOVE
6 KITS
8
522317
TIRE/WHEEL.15/6X6 PRO-TURF
9765545 & ABOVE
9765-2342 & ABOVE
10
522315
RIM - 15X6.00 - TAPERED R BRG
9765545 & ABOVE
9765-2342 & ABOVE
10
522316
TIRE - 15X6.00 KENDA/ PRO-TURF
9765545 & ABOVE
9765-2342 & ABOVE
10
521848
TIRE - 15 X 6.00 KENDA
9465276 to 9765544
9465-2044 TO 9765-2341
521827
TIRE - 15 X 6.00 DURO
9465276 to 9765544
9465-2044 TO 9765-2341
9
521494
BEARING - TAPER ROLLER
9765545 & ABOVE
9765-2342 & ABOVE
20
10
521744
BEARING RACE - OUTER
9765545 & ABOVE
9765-2342 & ABOVE
20
11
521493
GREASE SEAL
9765545 & ABOVE
9765-2342 & ABOVE
10
12
522314
SQUARE CASTOR (TAP. R. BRG) C/W ITEM 7
9765545 & ABOVE
9765-2342 & ABOVE
4
13
521320
SPACER WASHER - 1" (10 PCS/KIT)
9165101 - 9765544
9265-2002 TO 9765-2341
2 KITS
14
521787
WHEEL BUSHINGS - GREY 1.375 0D
9465276 to 9765544
9265-2044 TO 9765-2341
10
521319
WHEEL BUSHING KIT
9165101 to 9465275
9265-2044 TO 9765-2341
20
501319
BEARING
9165101 to 9465275
9265-2002 TO 9365-2043
20
15
521786
WHEEL ASSY 15 X 6.00 - KENDA
9465276 to 9765544
9465-2044 TO 9765-2341
10
521788
WHEEL ASSY 15 X 6.00 - DURO
9465276 to 9765544
9465-2044 TO 9765-2341
10
521772
RIM - FOR TD 1786 & TD 1788
9165101 to 9765544
9265-2044 TO 9765-2341
521318
TIRE AND RIM REPL. BY 521786
9165101 to 9465275
9265-2002 TO 9365-2043
10
16
521352
CASTOR - SQUARE
9165101 - 9765544
9265-2002 TO 9765-2341
4
17
521022
SPACER - RD 3/8" X 1" (6 PCS/KIT)
9765545 & ABOVE
9765-2342 & ABOVE
3 KITS
18
521021
SPACER - RD 1" X 1" (6 PCS/KIT)
9765545 & ABOVE
9765-2342 & ABOVE
3 KITS
19
521320
SPACER WASHER KIT (10PCS/KIT)
1 KIT
20
521038RD
LYNCH PIN - 5/16" (4 PCS/KIT)
9765545 & ABOVE
9765-2342 & ABOVE
2 KITS
21
522313
SWIVEL CASTOR (TAP. R BRG) C/W ITEM 7
9765545 & ABOVE
9765-2342 & ABOVE
6
22
522319
SWIVEL CASTOR RD COMPLETE
9765545 & ABOVE
9765-2342 & ABOVE
6
23
521317
CASTOR - 1" RD SWIVEL
9165101 to 9765544
9265-2002 TO 9765-2341
6
521833
CASTOR - 1"RD SWIVEL O/S (BLACK)
6
24
521327
WHEEL NUT (5 PCS/KIT)
9165101 & ABOVE
9265-2002 & ABOVE
2 KITS
25
522305
TIRE & RIM -ASSY CARLISLE TIRE
9165101 & ABOVE
9265-2002 & ABOVE
2
522306
TIRE - 18X9.5 TURF FOR 522305
9165101 & ABOVE
9265-2002 & ABOVE
2
521398
RIM - FOR 521028 & 521326
9165101 & ABOVE
9265-2002 & ABOVE
2
26
521746
WASHER (2 PCS/KIT)
9165101 & ABOVE
9265-2002 & ABOVE
1 KIT
27
521745
BEARING - TAPER ROLLER
9165101 & ABOVE
9265-2002 & ABOVE
2
28
521744
BEARING RACE - OUTER
9165101 & ABOVE
9265-2002 & ABOVE
2
29
521743
BEARING RACE - INNER
9165101 & ABOVE
9265-2002 & ABOVE
2
30
521754
HUB #3500 - TRANSPORT
9165101 & ABOVE
9265-2002 & ABOVE
2
31
521742
BEARING - TAPER ROLLER
9165101 & ABOVE
9265-2002 & ABOVE
2
32
521741
GREASE SEAL
9165101 & ABOVE
9265-2002 & ABOVE
2
33
521807
SPINDLE - TD 65 WELD-ON FRAME
9165101 & ABOVE
9265-2002 & ABOVE
2
COMES WITH ITEMS 26 (1), 7 (1)
34
521328
HUB ASSY 3500 LB. - 5 BOLT
9165101 & ABOVE
9265-2002 & ABOVE
2
35
521755
PRESS IN WHEEL STUD (5PCS/KIT)
-
36
528200
FENDER BRACKET R.H.
1
528198
FENDER BRACKET L.H.
1
37
524246
FENDER - TRANSPORT TIRE
2
38
528447
LIGHT BRACKET
2
39
O.L.
3/8" x 1" BOLT, LOCK & NUT
4
40
522420
BEARING KIT (ITEMS 9 (2), 10 (2), 11(1), 6 (1) )
8
OL - Obtain Locally AR - As Required QTY - Total Number Required for Complete Machine
19
Early Machines
