Project Source 0877823 - Care, Troubleshooting, and Warranty; Care and Maintenance; Troubleshooting Common Issues

8
OPERATING INSTRUCTIONS
2. Flush out any debris. Check for leaks.
3. Replace spray head (A).
QUICK CONNECTOR REMOVAL
1. Push quick connector housing upward.
Hold clip and housing together and pull
downward.
WARNING: Be careful in removal of quick
connector so as not to cut hands.
1
3
2
1
2
3
1
2
3
3-1
2
A
9
CARE AND MAINTENANCE
TROUBLESHOOTING
• Clean periodically with a soft cloth. Avoid abrasive cleaners, steel wool and harsh chemicals as
these will dull the nish and void your warranty.
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
Leak from under handle. Trim cap has come loose.
O-ring on cartridge is dirty or
damaged.
Tighten the trim cap. Clean or
replace O-ring.
Leaks from the hose under the
deck.
Hose and spray head
connection may be loose.
Tighten the connection
between the spray head and
hose.
Low water pressure. Quick connector is clogged
with debris.
Turn off water supply and
disconnect the quick connector
from the discharge tube.
Unscrew the quick connector
from the hose and clean under
running water. Screw back
onto hose and connect back
to discharge tube. Test water
ow. If water pressure is still
low then replace the quick
connector.
The hose does not retract. The weight is not installed in
the appropriate position.
Reinstall or readjust the weight.
