2
PACKAGE CONTENTS
PART DESCRIPTION QUANTITY
A Faucet body assembly 1
B Escutcheon 1
C Gasket 1
D Weight 1
HARDWARE CONTENTS (not shown actual size)
AA
BB
CC
Lock
Nut
Metal
Washer
Hex
Bolt
Qty. 1 Qty. 1 Qty. 2
B
C
D
A
