Project Source MT-25005L - TOILET INSTALLATION STEPS; Wax Ring and Floor Flange Mounting

3. Place the wax ring under the toilet.
Parts Used
A
A
DD
A
AA
Toilet
3
TOILET INSTALLATION
2.
10
x 1
x 1
x 2
4. Install the floor bolts onto floor flange (not
included). Position the toilet onto the floor flange
(not included). Make sure the fixing bolts are
aligned with the toilet holes. Tighten the wing
nuts onto bolts.
Parts Used
A
Toilet
Hardware Used
AA
T-Bolt
4
x 2
BB
Flat Washer
x 1
Hardware Used
DD
Wax Ring
Sewage Outlet
Floor
Flange
(not
included)
BB
x 2
CC
Wing Nuts
x 2
EE
Flat Metal Washer
CC
EE
AA
BB
