Project Source MT-25005L - TOILET AND WATER SUPPLY INSTALLATION; Reconnect Water Hoses; Water Supply Connection

5. Reconnect the water connection hoses on the
toilet seat. Hand tighten the fitting and then turn
an additional 1/4 turn with wrench.
Parts Used
A
A
A
Toilet
5
TOILET INSTALLATION
2.
11
x 1
A
x 1
Hardware Used
HH
Angle Valve
1. Connect the toilet water inlet hose with
the angle valve.
2. Open the angle valve to check for water
leakage at connection points.
Parts Used
A
A
HH
Toilet
WATER SUPPLY INSTALLATION
3.
x 1
6. Re-install the toilet seat by aligning the two
connection post and pressing firmly on the seat.
Parts Used
A
Toilet
6
x 1
Toilet Water
Inlet Port
Water
Inlet Hose
(Pre-install)
Constant
Valve
Angle Valve
(Special)
x 1
Hardware Used
GG
Wrench
