Projecta AC040 - Specifications

8
Part No. AC040 AC080
Input (nominal) 240VAC, 50Hz
Input Power 35.5W @ 6V, 63.5W @ 12V 128.5W
Output Voltage 6/12V 12V
Output Current 1, 4A 2, 8A
Minimum Start Voltage 2.0V
Back Drain 2mA
Charge Control
Battery Rescue Part 1 Battery voltage increases 500mA up 16.0V for 600mA up 16.0V for
>14.4V immediately 5 seconds, until voltage 5 seconds, until voltage
reduces to 13.5V reduces to 13.5V
Battery Rescue Part 2 Battery voltage increases 500mA up to 17.0V, 600mA up to 17.0V,
>14.4V after stage 1 if voltage drops to 13.5V if voltage drops to 13.5V
continue charging or continue charging or
2 hour limit then fault. 2 hour limit then fault.
Soft Pulse 2-6.0V 0.8A for 1 second then turn of for 2 seconds 2 hour limit
then fault
Pulse Charge part 2 6.0-10.5V Set current to 0.8A for 5 seconds then 2A for 5 seconds.
2 hour limit then fault.
Soft Start 10.5-12.0V 8 hour timeout then 1A 2A
transits to bulk
Bulk Set current to 13.6V (12V), Set current to 13.6V
6.8V (6V)
Absorption Constant voltage (12V) 14.4V (Normal), 14.7V (Winter),
7.2V (6V)
Absorption transits at following set points Slow(1A): <0.5A Slow(2A): <0.5A
Fast(4A): <0.6A Fast(8A): <1.2A
Winter(4A): <0.6A Winter(8A): <1.2A
6V(4A): <0.6A
Absorption timeout, transits to Analysis 6 hours
Analysis 60 second timeout, if battery drops <12.5V set F4 fault
Float (12V) 13.8V 2 min on, (12V) 13.8V 2 min on,
2 min. off (6V) Cutout 7.2V, 2 min. off
Cut in 6.5V
Battery Range
Deep Cycle 7-80Ah 14-160Ah
Automotive 40-480CCA 80-1000CCA
Marine 55-650MCA 110-1300MCA
Size (mm) 225 x 60 x 90 250 x 68 x 95
Weight 0.66kg 0.87kg
SPECIFICATIONS
