66
SPECIFICATIONS
P/No. IC700 & IC700W IC1000 IC1500
Type 7 stage 7 stage 7 stage
Input (Nominal) 240VAC, 50Hz 240VAC, 50Hz 240VAC, 50Hz
Input Power 110W 160W 240W
Output Voltage 12V 12V 12V
Output Current 7A, 4A, 2A, 1A 10A, 6A, 4A, 2A 15A, 8A, 4A, 2A
Minimum Start Voltage 2.5V 2.5V 2.5V
Back Drain 1mA 1mA 1mA (with remote 2mA)
CHARGE CONTROL
Desulphation High Frequency Pulse charge up to 11V
Soft Start Half the rated set current up to 12V
Bulk Set current up to: Set current up to: Set current up to:
14.1V (GEL) 14.1V (GEL) 14.1V (GEL)
14.4V (AGM) 14.4V (AGM) 14.4V (AGM)
14.7V (WET) 14.7V (WET) 14.7V (WET)
14.7V (CALCIUM) 14.7V (CALCIUM) 14.7V (CALCIUM)
Absorption Constant voltage until Constant voltage until Constant voltage until
current drops to: current drops to: current drops to:
1A – 0.15A 2A – 0.3A 2A – 0.3A
2A – 0.3A 4A – 0.6A 4A – 0.6A
4A – 0.6A 6A – 0.9A 8A – 1.2A
7A – 1.05A 10A – 1.5A 15A – 2.25A
Equalization Constant current (1.0–2.0A) Constant current (2.0A) up Constant current (2.0–2.2A)
(Calcium mode only) up to 16V then hold for 1 hour to 16V then hold for 1 hour up to 16V then hold for
or 12 hour timeout or 12 hour timeout 1 hour or 12 hour timeout
Analysis Monitors battery for 90 sec
Recondition Constant current Constant current Constant current
(0.15A – 1.05A) for (0.3A – 1.5A) for (0.3A – 2.25A) for
4 hours limited to: 4 hours limited to: 4 hours limited to:
14.1V (GEL) 14.1V (GEL) 14.1V (GEL)
14.4V (AGM) 14.4V (AGM) 14.4V (AGM)
16V (WET) 16V (WET) 16V (WET)
16V (CALCIUM) 16V (CALCIUM) 16V (CALCIUM)
Float 13.7V 13.7V 13.7V
POWER SUPPLY
Set Voltage 13.8VDC 13.8VDC 13.8VDC
Maximum Current 7A 10A 15A
BATTERY RANGE
Deep Cycle 7–140Ah 14–200Ah 14–300Ah
Automotive 40–800CCA 80–1000CCA 80–2000CCA
Marine 55–900MCA 110–1200MCA 110–2500MCA
Types of Batteries Most types of lead acid batteries including GEL, AGM, WET CELL and CALCIUM
Size (mm) IC700: 182 x 61 x 108 202 x 61 x 108 222 x 61 x 108
IC700W: 193 x 65 x 112
Weight IC700: 1.02Kg 1.15Kg 1.54Kg
IC700W: 1.08Kg
