“HARD WIRED” CONNECTION
When mounting the inverter in a vehicle, caravan, boat or cabin it may be preferable to use
longer DC battery cables than those supplied, so that the inverter can be placed in a more
convenient, cooler or more protected location.
If longer cables are required only use suitably insulated automotive battery cable according to the
following table (Note: B&S = AWG)
P/No. IM300 IM600 IM1000 IM2000
Up to 2m 8 B&S
(8mm2)
6 B&S
(14mm2)
3 B&S
(26mm2)
2 B&S
(32mm2)
3m 8 B&S
(8mm2)
3 B&S
(26mm2)
2 B&S
(32mm2)
0 B&S
(49mm2)
4m 6 B&S
(14mm2)
2 B&S
(32mm2)
0 B&S
(49mm2)
00 B&S
(64mm2)
6m 3 B&S
(26mm2)
0 B&S
(49mm2)
00 B&S
(64mm2)
Not
Recommended
UÊÌÊÃÊÀiVi`i`ÊÌ>ÌÊ>ÊVÀVÕÌÊLÀi>iÀÊÀÊ}ÊVÕÀÀiÌÊvÕÃiÊLiÊ«>Vi`ÊÊÌiÊÊ«ÃÌÛiÊ³®ÊiÊ
close to the battery.
P/No. IM300 IM600 IM1000IM2000
Fuse or Circuit
Ài>iÀÃÊÃâiÊ³®Ê"Þ
40AMP 100AMP 150AMP 250AMP
(or 2 x 150AMP
in parallel)
UÊÌÊÃÊÀiVi`i`ÊÌ>ÌÊ>Êi>ÛÞÊ`ÕÌÞÊL>ÌÌiÀÞÊÃÜÌVÊÜÌÊ>ÊVÕÀÀiÌÊÀ>Ì}Ê}iÀÊÌ>ÊÌiÊvÕÃiÊ
ÌÌi`ÊÊÌiÊÊ«ÃÌÛiÊ³®ÊiÊVÃiÊÌÊÌiÊL>ÌÌiÀÞÊÌÊ>ÜÊÌiÊÃÕ««ÞÊÌÊÌiÊ
ÛiÀÌiÀÊÌÊLiÊÃÜÌVi`Êvv]ÊÌÃÊV>Ê>ÃÊLiÊ>ViÛi`ÊLÞÊÕÃ}Ê>ÊVÀVÕÌÊLÀi>iÀÊÜVÊ>ÃÊ
a trip facility.
UÊ*ÃÌÛiÊ>`Ê i}>ÌÛiÊV>LiÃÊÃÕ`ÊLiÊÀÕÊVÃiÊÌ}iÌiÀÊÌÊÀi`ÕViÊV>LiÊ`ÕVÌ>Vi]Ê>`ÊLiÊ
protected from damage by corrugated conduit.
CORRUGATED CONDUIT
SWITCH
FUSE
10
