CONNECTIONS / CONTROLS & ACCESSORIES
After unpacking your inverter take a moment to check that you have all the correct accessories for
your model and familiarise yourself with the connections and controls.
P/No. IM150
Supplied:
U Operating instructions
U Fitted DC cord with accessory (Cigarette) plug (800mm)
U Spare blade fuse
P/No. IM300
FRONT
AC OUTPUT
SOCKET
POWER ON
SWITCH
FUSE DC CORDPOWER & FAULT
LIGHTS
REAR
CHASSIS GND
FRONT
AC OUTPUT
SOCKET
POWER ON
SWITCH
FUSE FANDC TERMINALSPOWER & FAULT
LIGHTS
REAR
CHASSIS GND
