P_MAZ_0001_SW
2
1
Fig. 8: Standard installation
1 Main line
2 Storage tank
Symbol Explanation Symbol Explanation
Metering pump Foot valve with filter meshes
Injection valve Level switch
Multifunctional valve Manometer
Legend for hydraulic diagram
Installation, hydraulic
26
