ProMinent Beta b BT4b Series User Manual

1 Identity code
Product range Beta b
BT4b Type Capacity
bar l/h
1000 10 0.74
1601 16 1.10
1602 16 2.20
1604 16 3.60
0708 7 7.10
0413 4 12.30
0220 2 19.00
BT5b
2504 25 2.90
1008 10 6.80
0713 7 11.00
0420 4 17.10
0232 2 32.00
Material of dosing head/valves
PP Polypropylene/PVDF. With the self-bleeding design (SEK): polypropylene/polypropylene
NP Clear acrylic/PVDF. With the self-bleeding design (SEK): Clear acrylic/PVC
PV PVDF/PVDF
TT PTFE + 25 % carbon /PTFE + 25 %
SS Stainless steel 1.4401/1.4571
Material of seals/diaphragm
T PTFE/PTFE-coated
E EPDM/PTFE-coated, only for PP and NP self-bleeding (SEK)
B FPM-B/PTFE-coated, only for PP and NP self-bleeding (SEK)
S Diaphragm with additional FPM coating for media containing silicate
F FDA-compliant
Dosing head design
0 without bleed valve, without valve spring only for NP, TT, SS and type 0232
1 without bleed valve, with valve spring only for NP, TT, SS and type 0232
2 with bleed valve, without valve spring only for PP, PV, NP not for type 0232
3 with bleed valve, with valve spring only for PP, PV, NP not for type 0232
4 design for higher-viscosity media only for PVT, type 1604, 2504, 0708, 1008, 0413,
0713, 0220, 0420
7 self-bleeding (SER) only for PV/NP, not for types 1000, 1601 and 0232
9 self-bleeding (SEK) only for PP/NP, not for types 1000 and 0232
Hydraulic connector
0 Standard connection in line with technical data
5 Connector for 12/6 hose, discharge side only
Identity code
5
