Page 30
8 Disposal
IMPORTANT
Please observe the applicable national regulations.
You may return the decontaminated used equipment to ProMinent Dosiertechnik
GmbH, Heidelberg, against prepaid postage.
9Technical Data
IMPORTANT
• The maximum operating parameters for the whole in-line probe housing
(e.g. pressure, temperature, flow) are the lowest maximum operating
parameters of the in-line probe housing components and sensors
(please refer to the individual operating manuals)!
• Please also take the technical data of all other parts used, e.g. sensors, and
their operating manuals into account!
Storage and transport temperature -10 °C ... + 60 °C
Humidity with flow sensor: max. 90 % relative humidity,
non-condensing
9.1 Flow Modules
Weight approx. 245 g (PG 13.5 module)
approx. 475 g (25 mm module)
Material all modules transparent PVC
all fittings grey PVC
seals FPM
calibration cup PP
mounting panel white PVC
Temperature max. 50 °C
Max. pressure without flow sensor, 30 °C: 6 bar
without flow sensor, 50 °C: 1 bar
with flow sensor, 30 °C: 2 bar
Flow rate max. 80 l/h (40 l/h recommended)
Measuring accuracy ±5 l
of the flow module
Pressure loss in flow module: 12 mbar (12 cm WS)
fitted modules PG 13.5 module: 2 mbar (2 cm WS)
25 mm module: 20 mbar (20 cm WS)
Disposal/Technical Data
