Dulcodes UV-Desinfektionsanlage
Identity code ordering system
Identity code ordering system
Please enter the identity code on the device label into the grey box below.
Notice:
S2Ca pump types: 60 Hz performance
data applies (as 60 Hz operation)
but max. 200 strokes/min.
S1Ca Sigma Control Type (S1Ca)
HM Power end, diaphragm
Pump typ: (figures 1+2 =back pressure [bar ],figures 3-5 =feed rate [l/h ])
12017
12 bar 20 l/h
12035
12 bar 42 l/h
10050
10 bar 50 l/h
10022
10 bar 26 l/h
10044
10 bar 53 l/h
07065
7 bar 65 l/h
07042
7 bar 50 l/h
04084
4 bar 101 l/h
04120
4 bar 120 l/h
Liquid end materials:
PV PVDF
SS Stainless steel
Seal material:
T PTFE seal
Displacement element:
0 Standard diaphragm
1 Double diaphragm with rupture indicator incorporating “Pump stopping” function
2 Double diaphragm with rupture indicator incorporating “Pump alarm” function
Liquid end version:
0 No springs
1 With 2 valve springs, stainless steel 1.4301, 0.1 bar
4 With relief valve,Viton
®
seal,no valve spring
5 With relief valve,Viton
®
seal,with valve spring
Hydraulic connection:
0 Standard threaded connector (according to technical data)
1 Union nut and PVC insert
2 Union nut and PP insert
3 Union nut and PVDF insert
4 Union nut and stainless steel insert
7 Union nut and PVDF hose nozzle
8 Union nut and stainless steel hose nozzle
Version:
0 With ProMinent
®
logo
1 Without ProMinent
®
logo
Electrical power supply:
U 3 ph, 230 V/400 V, ±10 %, 50/60 Hz
Cable and plug:
A 2 m European
B 2 m Swiss
C 2 m Australian
D 2 m USA
Relays:
0 No relay
1 With fault indicating relay (N/C)
3 With fault indicating relay (N/O)
4 As 1 with pacing relay
5 As 3 with pacing relay
Control variant:
0 Manual + external with pulse control
1 Manual + external + pulse control
+ analogue
P PROFIBUS
®
Access code:
0 No access code
1 With access code
Metering monitor:
0 Input with pulse evaluation
1 Input with permanent contact
evaluation
Stroke length
adjustment:
0 Manual
C Manual + calibration
S1Ca HM ___ ___ T ___ ___ ___ ___ U ___ ___ ___ ___ ___ ___ 01
Viton
®
is a registered trademark of DuPont Dow Elastomers.
