DO
1. Read the manual ; understand the operation, limitations and safety instructions before using the
product
2. Use good quality cables of the correct type, in the correct sockets
3. Listen to your sound ; if it’s distorted, reduce gain, volume or both
4. Use adequate amplification and speakers for your needs
5. Checks the mains supply in the venue ; use a mains checker e.g. Maplin product WD53H
6. Ensure your amp, speakers and all cables are free from damage
7. Protect your amp from moisture, smoke/fog machines and glitter cannons
8. Make and check all connections before you switch on
9. Set amp volume to ‘0’ at switch on. Slowly turn up, checking all speakers are working. If there are
problems turn the amp off and resolve them
DO NOT
1. Prevent airflow to your amp ; ventilation is required front and rear
2. ‘Daisy chain’ speakers. Run a maximum of 1x4 Ohm speaker or 2x8 Ohm speaker per amp channel.
3. Run amplifiers with the clip or limit lights on constantly
4. Send a clipped or overdriven signal from your mixer or source to the amp
5. Store your amp or speakers in a damp environment
6. Overload mains sockets ; Never run more than 1500W of amplifiers, lights or other electronic
equipment from one plug socket
7. Connect 2 amp channels, or 2 different amps to one speaker
8. Short circuit or cross-connect an amps inputs or outputs
FOLLOW THE SIGNAL PATH !
• Source output to mixer/preamp input (shielded signal cable),
• Mixer/preamp output to power amp input (shielded signal cable),
• Power amp output to speaker input (unshielded speaker cable).
- 1 -
TECHNICAL SPECIFICATION
- 8 -
Model 800 1000 1600
Stereo mode, 2 x 8Ω
load
150W ×2
Max power
800W max@8Ω 1000W max@8Ω1600W max@8Ω
200W × 2 250W × 2
Stereo mode, 2 x 4Ω
load
2 x 300W 2 x 400W 2 x 500W
Rated Output Power (RMS)
Bridge mode, 1 x 8Ω
load
400W x 1 500W x 1 800W x 1
Frequency range 20 Hz - 20kHz
THD >0.5% >0.1 %
Frequency response R
L
= 8Ω, Po = 1 W 0 dB, +0.5 dB, -1 dB f = 20Hz-20kHz
Channel separation ≥70 dB
S/N: 20 Hz-20 kHz >90 dB
Damping factor , R
L
= 8Ω, 1 kHz ≥200
Input sensitivity at rated power 0dBu
Input impedance
30KΩ／balanced, 15KΩ／unbalanced
POWER switch
2 x channel level knob
Front panel
Reset switch
Controls
Rear panel Stereo/Bridge mode switch
2 x &quarter; inch Jack (unbalanced) INPUT
2 x XLR (balanced)
Connections
OUTPUT
3 x Speakon
Power ON 1 x blue LED
Protect engaged 1 x red LED
Over temperature 1 x Orange LED
Signal Clip 2 x Green LED
Signal level 2 x VU Meters
Status Indicators
Bridge mode 1 x green LED
Amplifier protection
Over-temperature, short circuit, output DC,
high frequency and over load protection.
Cooling Variable speed brushless fan
120 V, 60 Hz (USA & Canada)
230 V, 50 Hz (Europe)
AC Power supply (factory set)
240V, 50Hz (Australia)
Dimension
485(w)×88(h)×400(d)mm (inc. handles) 19×2U×9
Weight 11.8kg 13.5kg 15.8kg
