Protec Algo-Tec 6300 - Table 2 - Addressable 6000 Loop Equipment Current Details

93-509-09 - Issue 2 Rev 2 Page 10 of 20 Copyright Protec Fire Detection PLC
TABLE 2 – ADDRESSABLE ‘6000’ LOOP EQUIPMENT CURRENT DETAILS
ADDRESSABLE DEVICES
QUIESCENT
LOOP CURRENT
(mA)
ALARM
LOOP CURRENT
(mA)
OPTICAL SMOKE DETECTOR
6000/OP
0.35 0.55
OPTICAL HEAT SMOKE DETECTOR
6000/OPHT
0.35 0.55
TEMPERATURE DETECTOR
6000/TEMP
0.35 0.55
OPTICAL HEAT CO SMOKE DETECTOR
6000/OP/HT/CO
0.45 0.65
CO HEAT DETECTOR
6000/HT/CO
0.35 0.55
IONISATION SMOKE DETECTOR
6000/ION
0.52 0.82
BREAK GLASS
6000/MCP
0.5 0.85
SOUNDER BASE
6000/ASB2
0.6 6
SOUNDER BASE WITH FLASHING
XENON BEACON - 6000/ASBEA2
0.6 10
RED SYMPHONY SOUNDER
6000/SYM2R
0.5 5
SOUNDER
6000/SSR2
0.65 5
SOUNDER
6000/SRZ2
0.5 20
BEACON
6000/PVR2
0.5
45 (Xenon)
5 Av / 12 pk (LED)
SOUNDER XENON BEACON
6000/SRZ2/PVR
0.5 75
MONITORED INPUT CLEAN CONTACT
OUTPUT BOARD - 6000/MICCO
1.3 5
CLEAN CONTACT OUTPUT BOARD
6000/CCO
0.6 10
MONITORED INPUT BOARD
6000/MIP
0.65 4
MONITORED INPUT WITH CLEAN
CONTACT OUTPUT - 6000/MIPCCO
0.7 15
