Protec Algo-Tec 6300 - Table 2 C - Addressable 6000 Loop Equipment Current Details Continued

93-509-09 - Issue 2 Rev 2 Page 12 of 20 Copyright Protec Fire Detection PLC
TABLE 2c – ADDRESSABLE ‘6000’ LOOP EQUIPMENT CURRENT DETAILS continued
ADDRESSABLE DEVICES
QUIESCENT
LOOP CURRENT
(mA)
ALARM
LOOP CURRENT
(mA)
LOOP BEAM DETECTOR
6000/BEAM – (MIP)
0.65 7
TALKING SOUNDER BASE
6000/ATSB2
0.7 17 (Bell tone)
6400 LOOP LCD
86 (No disablement)
1
93 av. (+Disablement)
96 pk
98 (No disablement)
1
101av. (+Disablement)
103pk
CIRRUS PRO INTERFACE
6000/CPRO
10 10
LOCAL CONTROL MODULE 0.7 + detectors + EOL 67mA
1
Figure assumes a supply fault, buzzer on and both LCD backlights on
