93-509-09 - Issue 2 Rev 2 Page 13 of 20 Copyright Protec Fire Detection PLC
TABLE 3 – ADDRESSABLE LOOP EQUIPMENT WITH AUXILIARY SUPPLY
CURRENT DETAILS
ADDRESSABLE DEVICES
QUIESCENT (mA) ALARM (mA)
LOOP 24V LOOP 24V
LOOP ADDRESSED SOUNDER BASE
WITH AUXILIARY SUPPLY
(6000/ASB4)
0.58 - 1.5 8
LOOP ADDRESSED SOUNDER BASE
WITH FLASHING BEACON (AUXILIARY
SUPPLY)
(6000/ASBEA4)
0.58 - 1.5 25 average
80 peak
1
LOOP ADDRESSED SOUNDER WITH
AUXILIARY SUPPLY
6000/SRZ4
0.5 - 2 20
LOOP ADDRESSED BEACON WITH
AUXILIARY SUPPLY
6000/PVR4
0.5 - 2 45
LOOP ADDRESSED SOUNDER BEACON
WITH AUXILIARY SUPPLY
6000/SRZ4/PVR
0.5 - 2 75
ZONE ALARM INTERFACE
6000/ZA
0.6 4 + zone load 4 35 + alarm load
(1A max)
16 WAY INTERFACE
6000/16WAY
2
7 18 + zone load
+ output board
load (5A max)
7 18 + zone load +
output board load
(5A max)
TABLE 4 – NON-ADDRESSABLE LOOP EQUIPMENT CURRENT DETAILS
NON-ADDRESSABLE DEVICE
QUIESCENT (mA) ALARM (mA)
LOOP 24V LOOP 24V
24V SOUNDER BASE
(6000/SB)
- - - 7
24V SOUNDER BASE WITH BEACON
(6000/SBEA)
- - - 25 average
80 peak
1
FLUSH ISOLATOR UNIT
6000/FIU
0.12 - 0.12 -
BOXED ISOLATOR UNIT
6000/IU
0.12 - 0.12 -
DUAL ISOLATOR BASE
6000/DIB
0.12 - 0.12 -
STANDARD BASE
6000/BASE
- - - -
RELAY BASE
6000/RBNC or 6000/RBNO
0.05 - 15 -
1
The peak values occur when the beacon is at its ‘on’ stage during flashing.
2
There are variants of this product depending upon the monitoring requirements.
