93-509-09 - Issue 2 Rev 2 Page 19 of 20 Copyright Protec Fire Detection PLC
6
6
3
3
0
0
0
0
S
S
P
P
E
E
C
C
I
I
F
F
I
I
C
C
A
A
T
T
I
I
O
O
N
N
POWER SUPPLY MAINS 230V AC Nominal ± 10% ( T1A 250V HBC Fuse )
WORKING VOLTAGE 21.5 - 30V DC
CURRENT CONSUMPTION 180mA WITHOUT LOOP LOAD @ 24V DC
MAINS FAILED, PRINTER STATIONARY
MAXIMUM LOOP CURRENT 600mA per loop
ANALOGUE ADDRESSES 4 LOOPS, 191 ADDRESSES PER LOOP
(Maximum of 512 Detectors and Manual Call Points to comply with En54)
ZONES 32
ALARM OUTPUTS i) 4 MONITORED 24V DC ( T1A 250V FUSES )
ii) 2 NON MONITORED - (CONTACTS 1A RATED @ 24V DC)
iii) LOOP ADDRESSABLE OUTPUT DEVICES, SUBJECT TO THE
FOLLOWING PARAMETERS NOT BEING EXCEEDED: -
THE MAXIMUM NUMBER OF DEVICES PER LOOP
THE MAXIMUM LOOP LENGTH
THE MAXIMUM LOOP CURRENT.
MAXIMUM ALARM LOAD 3A WITH INTEGRAL POWER UNIT (INCLUDING LOOP CURRENT
AND INTERNAL PANEL CONSUMPTION).
FIRE STATION OUTPUT MONITORED 24V DC OUTPUT RATED @ 20mA max
FAULT OUTPUT SINGLE POLE CHANGEOVER CONTACTS - (1A RATED @ 24V DC)
SERIAL COMMUNICATIONS 2 WIRE RS485 COMMS + 2 WIRE POWER
NETWORK 2 WIRE RS485 LOOP
INTEGRAL CHARGER 3A SWITCH MODE (Protec series 9000 PSU)
INTEGRAL BATTERIES 4 x 6V 10Ah Sealed lead acid
(Lynteck OL Models) 2 x 12V 26Ah Sealed lead acid (when using the external battery box
mounted beneath the panel)
AUXILIARY 24V OUTPUT 24V DC ( F1A 250V FUSE )
INTERNAL PRINTER SUPPLY 24V DC ( F1A 250V FUSE )
TEMPERATURE RANGE 0-40°C
HUMIDITY LIMIT 85% NON-CONDENSING
ENVIRONMENT The 6300 meets IP30. It must be mounted in a dry position that does not
exceed the temperature or humidity limits specified above.
DIMENSIONS 385(H) x 440(W) x 145(D)
ENCLOSURE Storm grey textured enclosure smooth inner door with molded v-rated
polycarbonate lockable front door
MOUNTING 3 points surface mount
