Proteco ACE User Manual

ACE TA
2
ACE TI
ACE TA
ACE TI
1
2
3 4
5
1
2
3 4
5
130
Ace 3 = 815 mm - Ace 4 = 915 mm
Ace 3 = 1135 mm - Ace 4 = 1335 mm
130
Ace 4 TA = 1040 mm
Ace 3 TI Ace 4 TI Ace 4 REV
230V ~ 50Hz 230V ~ 50Hz 230V ~ 50Hz
1,2 - 1,7A 1,2 - 1,7A 1,2 - 1,7A
300W 300W 250W
10µF 10µF 8µF
150°C 150°C 150°C
3000 N 3000 N 2500 N
44 44 44
1400 rpm 1400 rpm 900 rpm
120° deg 120° deg 120° deg
17” 22” 22”
350 Kg 400 Kg 350 kg
2,0 m 3,0 m 3,0 m
40% 40% 40%
Ace 3 TI 24 Ace 4 TI 24 Ace 3TI 115 Ace 4 TI 115
24V dc 24V dc 115V ~ 60Hz 115V ~ 60Hz
0,5 - 0,75A 0,5 - 0,75A 3,1 - 3,3A 3,1 - 3,3A
50W 50W 300W 300W
__ __ 20µF 20µF
__ __ 150°C 150°C
2500 N 2500 N 3000 N 3000 N
44 44 44 44
1600 rpm 1600 rpm 1700 rpm 1700 rpm
120° deg 120° deg 120° deg 120° deg
15” 20” 15” 18”
250 Kg 300 Kg 350 Kg 400 kg
2,0 m 3,0 m 2,0 m 3,0 m
80% 80% 40% 40%
Ace 4 TA Ace 4 TA 24 Ace 4 TA 115
230V ~ 50Hz 24V dc 115V ~ 60Hz
1,2 - 1,7A 0,5 - 0,75A 3,1 - 3,3A
300W 50W 300W
10µF __ 20µF
150°C __ 150°C
3000 N 2500 N 3000 N
44 44 44
1400 rpm 1600 rpm 1700 rpm
110° deg 110° deg 110° deg
22” 20” 18”
350 Kg 200 Kg 350 Kg
2,5 m 2,5 m 2,5 m
40% 80% 40%
Motor power supply
Max draw.
Power
Capacitor
Thermal protection
Adjustable thrust
Protection rating
Revolutions
Opening angle
Opening time (90°)
Leaf weight
Leaf length
Duty cycle
2.2 KIT CONTENT
Motor power supply
Max draw.
Power
Capacitor
Thermal protection
Adjustable thrust
Protection rating
Revolutions
Opening angle
Opening time (90°)
Leaf weight
Leaf length
Duty cycle
1 ACE Swing operator
2 SPIP0770 Rear RH bracket T1
SPIP0870 Rear LH bracket T1
3 MGR1410Z Fixing pack
MPE1226
4 SPIA0270 Front bracket S3
5 Release key
1 ACE Swing operator
2 SPIP0770 Rear RH bracket T1
SPIP0870 Rear LH bracket T1
3 MGR1410Z Fixing pack
MPE1226
MRO12Z
MDAM12AB
4 SPIA0370 Front bracket S4
5 Release key
2.3 DIMENSIONS
