Proteco ACE User Manual

5
B
A
C
D
90°
ACE 3 TI = max 150 mm
ACE 4 TI = max 250 mm
ACE 4 TA = max 200 mm
A
B
90°
D
Fig. 8
ACE 3 TI
ACE 4 TI
ACE 4 TA
Tab. 1
Recommended installation (90° opening)
A + B= C (motor stroke)
Ace 3 TI C = 300 mm
Ace 4 TI C = 400 mm
If the ideal scenario of A and B is not applicable, refer to the below table to determine the brackets position
(values are expressed in mm).
Rear bracket
Rear bracket
Rear bracket
Minimum leaf length
Minimum leaf length
Minimum leaf length
INNER VIEW
OUTER VIEW
INNER VIEW
OUTER VIEW
