SAFETY CRITERIA
1 Attention: before beginning any kind of procedure of installation is absolutely Gate fixed in the middle of the pillar (Fig. D)
necessary to read all this manuall. In this case the maximun al opening corner of the gate is 90°.
2 Test/Control that the performances of the actuator auswer to your installation Gate fixed on the edge pillar (Fig. E)
needs. In this case the gate can be opened with a corner greater than 90°.
3 Besides control that: Pay attention to this: growing the distance of the actuator from the edge of the pillar
• The gare hinges are in good conditions and perfectly fattened. measure B, the opening angle of the gate grows.
• The gate has mechanicall stops in the opening and the closing.
HEIGHT INSTALLATION (Fig. G)
INSTALLATION ADVICE Calculate the height of the actuator installation according to the gate's shape and the
Connections: fastening possibility.
• See the “Scheme functional ” and refer to the control central scheme. a) If the gate has a big structure you can position it at any highness with no limits.
• The electric cable in the exit from the actuator must be tight, but do an ample curve b) If the structure is light is necessary to put the operator as muca as possible to the
towards the bottom in order to avoid the reflux in the inside of the actuator itself. (Fig. Q) centre of the gate (in heigt).
• The adjustment must be effected when the device has no power supply. Position 1 Central beam of the gate
• Foresee a omnipolar breaking device near to the apparatus (the contact must Position 2 Stiffen of the gate
measure at least 3 mm).
Always protect the power supply using a 6A automatic switch, or a 16A single-phase FIXING THE ANCHOR PLATE
switch fises. To dawel or to soldel the anchor plate on the little pillar near to the gate, paynig attention
• The power supply lines the motors, to the control unit and the connection lines to the to the quotes indicate above.
outfits must be separated to avoid troubles which could generate problems in the In case of clamping with expanding loose pieces, use metallic loose pieces Ø 13 mm and
installation working. consider that the loose piece has to be positioned at 30/35 mm distant from the edge of
• Any outfits (of control or safety) eventually connected to the control unit must be the little pillar to avoid the possibility of broke.
tension free. In case of wolling pillar use chemichal loose pieces, or resine loose pieces, or a
Spare parts: connectly wolled clamp.
• Use esclusively original spare parts. It is possible to use the plate, in two different ways, for right or left actuator, according to
• The batteries should be put with industril waste and not with domestic refuse . the particulary exigences. (Fig. H / I)
(Law n. 475/88).
MOTOR POSITION AND ARTICULADED ARM
Installation:
Put the motor on the anchor plate, paying attention to the exit pin of the motor which
• In order to use correctlythe product and to exclude the possibility of injury or
1
must be turned to the interior of the gate.
damage, refer to the "Generals" page enclosure, which is an integrated part of this
Put together the three parts of the articulated arm. ( Fig. M)
manual.
2
The upright arm with the arm, and the arm with the clamp with screws T.E. 12x35,
• The use of this equipment must be in observance of the safety standards in force in
S3
self loking huts M12 and wasther Ø 12 mm.
the country where it is installed, as well as the standards governing proper
Unclamp the motor using the normal key. (Fig. L)
installation.
3
Put the articulated arm on the exit tree of the motor and fix with a 8 x 16 screw T.E
4
Warranty:
and PFL 8x32 washer. (Fig. L)
• The warranty supplied by the manufacturer becomes volid in the event of
Extend the articulated arm till to positionate the fixing clamp on the gate.
interference, carelessness, improper use, lightening damage, power surges or use
5S3
The best situation is given when the arm forms a little angle as shown in Fig. C.
by unqualified personnel.
Weld screw the clamp to the gate.
• The warranty will also become in the following event: Failure to observe the
6S3
instructions given in the manuals supplied with the product.
(fig. R)
The application of any part in a manner differing from that provided for current
LIMIT SWITCH REGULATION
Set the motor thrust
legislation or the use of spare parts which are unsuitable and/or not approved by
1
Give an opening impulse.
manifacturer.
2
When the leaves reach the opening mechanichal limit switch it is necessary to place
• The manifacturer cannot be helb responsible for damages due to impropre or
3
the Cam of the micro limit switch and to fix it screwing it down without forcing.
unresonable use.
4 Give a closing impulse.
5 When the leaves reach the closing mechanichal limit switch it is necessary to put the
INSTALLATION INSTRUCTION SEQUENCE
Cam of the limit switch and fix it by screwing it without forcing.
1 Before the installation, analyse the risks referring to the chapter “Generalities” of
Regulate the motor thrust (as per the control unit instructions) It is possible to Stop
this instructions manual, fill the technic table and eliminate the risks noticed.
6
the working stroke of the gate with a force of 150N (about 15 Kg)
In case of more risks, foresee the installation with security system.
N.B. This kind of motor has been studied to be used with micro-limit swith.
2 Test the security laws of the “Security Criteria”.
If you do not use them unclamp the motor can be more difficoult and you could have
3 Identify the right actuator and left actuator.
a more rapid damage of the mechanical parts.
4 Controll all the components.
5 Identify the fixing point on the gate and then on the pillar.
(Fig. A)
To lock the at the little pillar.
MECHANICAL STOP
6 “Anchor plate”
At this point you need to position the machanical Stop to proced respectively, to the
7 To lock the gear motor at the “Anchor plate”.
wing’s closing and opening Stop.
8 To unclamp the actuator.
9 To put the articulated arm.
To lock the clamp at the gate.
EXTERNAL OPENING GATE.
10 S3
If the gate opens till the exterior it is possible to put the actuator between the two pilar.
11 Strech the wires as in the “Functional swing gate scheme”.
(Fig. N)
Connect the central and all the accessoires
Gate fixed in the middle of the pillar
12
In this case the maximun al opening corner of the gate is 90°.
13 Program the radio receptor
Gate fixed on the edge pillar (Fig. O)
14 Program working times
(Fig. P)
In case of badworking, see the .
Exterior fixed the pillar
“Anomalies and advises”
In this case the gate can be opened with a corner greater than .
If you do not find any solution call the nearest Assistence centre.
90°
Pay attention to this: reducing the distance of the actuator from the edge of the pillar
measure A, the opening angle of the gate grows.
ELECTRO LOCK
Please notice that the electric lock must be installed on the swing that opens first and
must be connected with the terminal board of the control unit.
RELEASE OF THE ACTUATOR
- To keep out the cap on the fore part of the motor. (Fig. L)
Position of the electric lock: (Fig. B)
- To put and to wheel of in time sense the endowed key.
Lock between the wings
90°
Position 1:
Not it is possible to open and to close the gatem handly.
(in this case is necessary to use the bolt RT15 on the second wing).
- To re-hook the actuator, to wheel in the contrary sense the endowed key.
Position 2: Lock in the floor (in this case the utilisation of the bolt is not necessary).
It is not necessary the gate is in a particurety position, because at the first order all the
Remember to remove the lock or at least block the lock in opening position and take
volvers are restored.
away all the bolts of lock.
RIGHT OR LEFT ACTUATORS ACTUATORS (Fig. A)
The actuators are supplied in Right or Left version.
Right or left are established looking the gate from the side where the actuators are
installed, if the hinges are on the right the actuator is right, if they are on the left the
actuator is left.
Conseguentely the actuator must be installed with the exit pin, positioned in the hinges of
the gates.
DETERMINATION OF FIXING MEASURES
To determinate the clamping point it is necessary pay attention to this:
• A = 300 mm (Fig. C)
Maximum dimension betwen the axis of the gate and the edge of the pillar.
• B = 30 mm (Fig. C)
Maximum dimension from the anchor plate to the edge of the pillar.
(to avoiod the possible brake of the edge)
• D = 14 mm (Fig. F)
Vertical distance from the clamping point of the clamp S3 on the gate, to the anchor
plate on the little adge.
ENGLISH
