4. Set the decade resistor and the Model Z9216 according to the values in the Resistance
Accuracy Table below. Verify that the readings fall within the acceptable values. Record the
results.
Resistance Accuracy Table
Resistance
Range Conditions Minimum Maximum
10.0Ω 3 1kHz, Series 9.978 10.022
25.0Ω 3 1kHz, Series 24.945 25.055
25.0Ω 3 10kHz, Series 24.933 25.067
25.0Ω 3 100kHz, Series 24.908 25.092
100.0Ω 3 1kHz, Series 99.78 100.22
100.0Ω 2 1kHz, Series 99.78 100.22
400.0Ω 2 1kHz, Series 399.12 400.88
400.0Ω 2 10kHz, Series 398.92 401.08
400.0Ω 2 100kHz, Series 398.52 401.48
1.600KΩ 2 1kHz, Parallel 1596.48 1603.52
1.600 KΩ 1 1kHz, Parallel 1596.48 1603.52
6.400 KΩ 1 1kHz, Parallel 6385.92 6414.08
6.400 KΩ 1 10kHz, Parallel 6382.72 6417.28
6.400 KΩ 1 100kHz, Parallel 6376.32 6423.68
25.000 KΩ 1 1kHz, Parallel 24945 25055
25.000 KΩ 0 1kHz, Parallel 24945 25055
100.000 KΩ 0 1kHz, Parallel 99780 100220
100.000 KΩ 0 10kHz, Parallel 99730 100270
400.000 KΩ 0 1kHz, Parallel 399120 400880
* if the Q value is greater than 0.1, the allowed tolerance must be multiplied by (1+Q)
