Data Error 3 CPU RAM failed a read/write test.
Det Error 6 The square wave multiplier failed its DC rejection test.
Drv Error i 7 The output drive circuitry failed its test. i is an error code indicating the
failure point.
i
error
0 100 Hz amplitude failure
1 120 Hz amplitude failure
2 1 kHz amplitude failure
3 10 kHz amplitude failure
4 100 kHz amplitude failure
5 0.25 V amplitude attenuator failure
6 0.1 V attenuator failure
Freq Error i 5 The frequency clock generator failed its test. i is an error code indicating
the failure point.
i
error
0 100 Hz failure
1 120 Hz failure
2 1 kHz failure
3 10 kHz failure
4 100 kHz failure
Gain Error 8 The instrumentation amplifier failed its gain test. i is an error code
indicating the failure point.
i
error
0 the ×2 gain failed
1 the ×4 gain failed
2 the ×8 gain failed
3 the ×20 gain failed
Out Error 9 The source impedance selection circuitry failed its test. This error can
occur if a part is in the fixture during the test. i is an error code indicating
the failure point.
i
error
0 the 100 kΩ range failed
1 the 6.4 kΩ range failed
2 the 400 Ω range failed
3 the 25 Ω range failed
4
