INSTALLING THE BLADE GUARD
If not already installed, install the included blade guards by snapping them in.
Make sure the blade guards are secure and snug.
NOTE:
Loose blade guards may interfere
with propeller movement and cause
a crash. If the drone crashes, double
check to make sure the blade guard
is not loose. If it is, re-tighten
before flying.
INSTALLING THE PHONE CLAMP
1. Remove the clip cover from the remote control.
2. Insert the phone clamp into the now empty slot on the remote.
3. Open the clamp to fit the phone.
REMOTE BATTERY, BLADE GUARD & PHONE INSTALLATION
1. Install batteries carefully.
2. Do not mix old and new batteries.
3. Do not mix different types of batteries.
Unscrew and remove battery cover from controller. Insert 4 x ‘AA’ batteries
according to indicated polarities. Replace and screw back in battery cover.
4
