PROVA 123 - Process Calibrator Electrical Specs

27
III. Electrical Specification (23
°
C ± 5
°
C, 10 minutes after power is on)
mA DC Current (1K
Ω
Max. Load, 24V Loop Supply)
Range Resolution Accuracy
4 - 20mA, 0 - 20mA, 0 -24 mA
1
μ
A ± 0.025% ±3
μ
A
Beeper warning when output is open and specified current output > 1mA
mV, V DC Voltage (1mA Supply Current)
Range Resolution Accuracy
0 - 100.00mV
10
μ
V ± 0.05% ± 30
μ
V
0 - 10.000V 1mV ± 0.05% ± 3mV
0 - 1.0000V
100
μ
V ± 0.05% ± 300
μ
V
Beeper warning when output is short and specified voltage output > 10mV
K, J, E, T type Thermocouples( 1
°
C,1
°
F Resolution,1K
Ω
load Min. )
Range Accuracy Range Accuracy
K: -200 to -100
°
C ± 2.0
°
C K: -328 to -148
°
F ± 3.6
°
F
K: -100 to 0
°
C ± 1.1
°
C K: -148 to 32
°
F ± 1.8
°
F
K: 0 to 1370
°
C ± 0.8
°
C K: 32 to 2400
°
F ± 1.5
°
F
J: -100 to 0
°
C ± 0.9
°
C J: -148 to 32
°
F ± 1.6
°
F
J: 0 to 760
°
C ± 0.7
°
C J: 32 to 1400
°
F ± 1.2
°
F
E: -100 to 0
°
C ± 0.9
°
C E: -148 to 32
°
F ± 1.6
°
F
E: 0 to 700
°
C ± 0.7
°
C E: 32 to 1292
°
F ± 1.2
°
F
T: -200 to 0
°
C ± 1.0
°
C T: -328 to 32
°
F ± 1.8
°
F
T: 0 to 400
°
C ± 0.8
°
C T: 32 to 752
°
F ± 1.5
°
F
