ORiNOCO
®
802.11n Access Points - Software Management Guide 59
Figure 5-21 RADIUS Server Profile
Tabulated below are the ‘RADIUS Server Profile’ parameters and the method to configure the configurable parameters:
Parameter Description
Profile Name Specifies the RADIUS profile name which is used to identify a set of four RADIUS servers
configured one per Accounting, Authentication, Secondary Accounting and Secondary
Authentication.
Max
Re Transmissions
Specifies the maximum number of times, an authentication request is retransmitted.
By default, it is set to 3. To configure, enter the Max ReTransmissions in the range of
0 to 3.
Message Response
Time
Specifies the response time, for the RADIUS server to acknowledge a request.
By default, it is 3. To configure, enter the Message Response Time in the range of 3 to 12
seconds.
Re Authentication
Period
Specifies the time period for the AP device to re-authenticate the client with the RADIUS
server.
By default, the Re Authentication Period is 0. To configure, enter the value in the range of
900 to 65535 seconds.
: Re Authentication Period is not applicable to wireless clients using ‘RADIUS MAC
Authentication’ and is disabled if the value is set to “0”.
RADIUS Server Profile Table
Server Type A read-only parameter which displays the type of RADIUS Server. Server Type may vary
between Primary Accounting Server, Secondary Accounting Server, Primary
Authentication Server and Secondary Authentication Server.
IP Address Specifies the IP address of the RADIUS server configured. To configure, enter the IP Address
in the box.
