ORiNOCO
®
802.11n Access Points - Software Management Guide 121
Click Refresh to view the updated Interface statistics (Ethernet/Wireless 1/Wireless 2) and click Clear to clear the interface
statistics.
7.2 Station Statistics
‘Station Statistics’ allow you to monitor the wireless clients associated with the device. To view the station statistics, navigate
to MONITOR > Station Statistics. The Station Statistics screen appears.
Figure 7-3 Station Statistics
The Station Statistics screen contains the following information:
Tx RTS Failures Specifies the total number of RTS frames requests that receive no response.
Tx Fragment Count Specifies the total number of fragments that are transmitted and acknowledged.
Rx Fragment Count Specifies the total number of fragments that are transmitted and received successfully.
Tx Failed Count Specifies the total number of undelivered frames.
Duplicate Frame
Count
Specifies the total number of frames transmitted successfully, in a duplicate fragment.
VAP Statistics
In Octets Specifies the total number of octets received on the interface.
In Unicast Packets Specifies the number of unicast sub-network packets delivered to the higher level protocol.
In Non - Unicast
Packets
Specifies the number of non-unicast sub-network packets delivered to the higher level
protocol.
Out Octets Specifies the total number of octets transmitted out of the interface.
Out Unicast Packets Specifies the total number of packets requested by the higher level protocol and then
transmitted to the non-unicast address.
Out Discards Specifies the number of error-free outbound packets that are discarded to free up the buffer
space.
Parameter Description
MAC Address Specifies the MAC address of the wireless client.
