ORiNOCO
®
802.11n Access Points - Software Management Guide 80
Tabulated below are the ‘Static MAC Address Filter’ parameters and the method to configure the configurable parameters:
Click Add, to save the configured entry.
:
• A maximum of 200 Static MAC Filters can be added.
• Wired and Wireless MAC address cannot have broadcast and multicast MAC address.
5.8.3 Advanced Filters
The ‘Advanced Filters’ feature enables you to block the specific IP Protocol traffic on the network.
Navigate to CONFIGURATION > Filters > Advanced Filters. The Advanced Filters screen appears.
Figure 5-41 Advanced Filters
Parameter Description
Wired MAC Address Specifies the MAC address of the device on the wired network that is restricted from
communicating with a device on the wireless network. To configure, enter a Wired MAC
Address.
Wired MAC Mask Specifies the range of the wired MAC addresses to which the filter is applied. To configure,
enter a Wired MAC Mask.
Wireless MAC
Address
Specifies the MAC address of the device on the wireless network that is restricted from
communicating with a device on the wired network. To configure, enter a Wireless MAC
Address.
Wireless MAC Mask Specifies the range of the wireless MAC addresses to which the filter is applied. To
configure, enter a Wireless MAC Mask.
Comment Specifies the user-comment on a Static MAC Filter table entry.
Status Specifies the status of the filter added. Enable the status to apply filters between the wired
and wireless devices. By default, it is enabled. To disable, click Disable from the Status box.
