Translation of the Original
Operating Instructions
Dear Customer ……………………………………………11
Description of the machine ………………………………11
Legend
(Fig. 1) ……………………………………………11
Technical data………………………………………………12
Commissioning ……………………………………………12
Setting up the device ……………………………………12
Assembling the work table………………………………12
Things
to know about commissioning and on working 12
Using avacuum cleaner ………………………………13
Sawing ……………………………………………………13
Free hand sawing ………………………………………13
Sawing with the angle stop ……………………………13
Mitre cuts …………………………………………………13
Maintenance, settings and care …………………………13
Adjusting the saw band tension ………………………13
Replacing the saw band…………………………………13
Adjusting the upper saw band guide …………………14
Adjusting the position of the upper saw band guide …14
Adjusting the upper saw band guide to the respective
saw band width …………………………………………14
Adjusting the upper saw band guide to the respective
saw band thickness ……………………………………14
Checking and adjusting the lower saw band guide …14
Replacing the plastic rings of the running wheels …14
Operation with the diamond saw band …………………14
Things to know about working with diamond saw
bands ……………………………………………………14
Cleaning, maintenance and care…………………………15
Changing the table insert ………………………………15
Disposal …………………………………………………15
EC Declaration of Conformity ……………………………15
Spare parts list ……………………………………………67
Exploded view………………………………………………71
Dear Customer,
The use of these instructions
•makes it easier to become acquainted with the device,
•prevents malfunctions due to improper handling, and
•increases the service life of your device.
Always keep these instructions close to hand.
Only operate this device with exact knowledge of it and
comply with the instructions.
PROXXON will not be liable for the safe function of the
device for:
•handling that does not comply with the usual intended
use,
•other application uses that are not stated in the instruc-
tions,
•disregard of the safety regulations,
You will not have any warranty claims for:
•operating errors,
•lack of maintenance.
For your safety, please comply with the safety regulations
without fail.
Only use original PROXXON spare parts.
All rights reserved for further developments within the
meaning of technical progress. We wish you much suc-
cess with the device.
Description of the machine
The Micro bandsaw MBS 240/E cuts steel, non-ferrous
metal, wood and plastic and equipped with adiamond
band it will also cut glass and ceramics.
The MBS 240/E has a230 volt motor with electronic
speed control to set the correct band speed for optimal
work results.
The work table can be adjusted to any angular position
from 0° to 45°, thus enabling clean and precise cuts.
The diagram shows the control range for most materials.
We recommend original PROXXON replacement saw
bands.
Legend (Fig. 1)
1. Housing cover
2. Fastening screw
3. Housing
4. Adjusting screw
5. Clamping screw
6. Guide rod
7. Saw blade cover
8. Saw band guide
9. Saw band
10. Work table
11. Suction connection
12. Device base
13. Adjusting knob
14. Device switch
15. Diagram
16. Push-rod
Scopeofdelivery:
1pc. Bandsaw MBS 240/E
1pc. Angle stop
1pc. Rubber connecting piece
1pc. Push-rod
1pc. Work table including fastening screw
1pc. Operating manual with safety instructions
11
