Note
Automatic commissioning can be started via software PSCS -> See relevant operation manuals
11.2 Manual Commissioning
If both cut-offs are selected to be „by position“, the actuator must be commissioned manually using the software
PSCS or the control box PSC.
Mount the actuator to a valve, wire it and switch the power on, according to these instructions. Permanently apply
the set-value for the closed position, or the input signal „close“.
Drive the actuator to the closed position of the valve using software PSCS or control box PSC. The open position of
the valve will be calculated in accordance with the programmed valve stroke.
After manual commissioning, the actuator is ready for use. The green LED is glowing permanently.
Note
If the parameterised valve stroke, starting from the adjusted closed position, exceeds the possible actuator stroke,
then the operating stroke will be reduced to the resulting maximum possible value.
Caution!
If the LEDs display other types of signals than
“flashing green” or “glowing green permanently”,
please refer to the chapter 15 on “Tracing Faults”.
Caution!
The mains supply must not be interrupted during
the commissioning run!
