PS Engineering Inc. ®
PAR200A Audio Selector Panel, COM radio Controller and Intercom System
Installation and Operator’s Manual
200-228-0200 Appendix B Rev. 4, DEC. 2017
Tray and cutout dimensions
Caution: Apply steady pressure to the bezel while screwing the unit into the tray to
ensure even seating of the unit and connectors.
6.1 TY91/92 Radio Installation Drawings
Not to Scale. Dimensions in millimeters, (inches)
(6.30)
(1.89
)
(3.54)
(.85)
(5.44)
(Ø.187)
(2.52
)
(1.25
)
(1.18
)
