PS Engineering PAR200A User Manual

PS Engineering Inc. ®
PAR200A Audio Selector Panel, COM radio Controller and Intercom System
Installation and Operator’s Manual
200-228-0200 Page 1-4 Rev. 4, DEC. 2017
TY92L VHF Transceiver Specifications
Radio Type
Amplitude Modulation (AM) Aircraft Transceiver
Channels (Transmit & receive)
760 channels, 25KHz spacing
2280 channels, 8.33 kHz spacing
118.000 – 136.992MHz
Frequency Selection
On PAR200A Audio Panel
Frequency Display
Alpha/numeric LCD display (with backlighting) on
PAR200A
Frequency control
PLL frequency synthesis, which is microprocessor con-
trolled Memory is store in non-volatile EPROM
Power consumption Receive (no signal)
Transmit
2.8W @ 28VDC
80 W @ 28VDC, 3.2A
Input Voltage
18-33 VDC 5A Circuit Breaker. (28 V Systems only)
Power output
16 watts (nominal) VSWR Tolerance < 2:1 for best op-
eration (5:1 without damage)
Receiver sensitivity
-6dB SINAD @ 5µV (1KHz audio with 70% modula-
tion)
Data Interface
RS232
Headset volume output
Nominal 100 milliwatts output to 600 Ω
Temperature range
-20 to +70 degrees Celsius
Stability
< +/- 4.00 ppm
Dimensions
W-2.5” x H-1.9” x D6.3” (plus 1.5” for harness) W-
66mm xH-48mm x D-160 (plus 35mm for harness)
Weight
.77 lbs. (.350 kg)
FCC ID:
VZI00879
1.6 EQUIPMENT SUPPLIED
One ea. of the following items:
Model
Description
PS Part Number
Trig P/N
PAR200A
PAR200A Audio Panel with intercom and radio function control
050-228-0200
And ONE of the TY9X below
TY91(L)
VHF Communications Transceiver (6 watts)
050-228-8744
00882-00-05
TY92(L)
VHF Communications Transceiver (16 watts)
050-228-8745
01196-00-05
OR
PAR200A
PAR200A Audio Panel with intercom and radio function control
050-228-0202
And ONE of the TY9X below
TY91(L)
VHF Communications Transceiver (6 watts)
050-228-8744
00882-00-05
TY92(L)
VHF Communications Transceiver (16 watts)
050-228-8745
01196-00-05
Installation Kit: 250-890-0000, contains:
Description
Quantity
Part Number
PAR200A installation rack assembly
1
430-890-0040
PAR200A Rack back plate
1
430-890-0050
44-pin connector kit
2
120-891-2045-
Backshell, connector
2
625-025-2465
Backshell Retainer
2
431-891-0100
4 40 X 7/16 screw w/nylon patch
4
475-440-0007
4 40 X 3/8 screw w/lock washer
4
475-440-1038
4 40 X 1/8 screw w/lock washer
2
475-440-0001
Solder Lug
2
475-009-0001
Cable Clamp
1
625-001-0002
#6-32 x ½” Flat head Philips screw
6
475-632-0012
#6-32 Clip Nut
6
475-630-0002
