PS Engineering Inc. ®
PAR200A Audio Selector Panel, COM radio Controller and Intercom System
Installation and Operator’s Manual
200-228-0200 Page 1-5 Rev. 4, DEC. 2017
TY91/92 Installation Kit 250-228-0200, Containing:
Description
Quantity
Part Number
DB 25 Connector , Crimp type
1
425-025-0010
DB 25 Connector hood
1
625-025-0001
DB 25 Thumb Screws 4-40 x 1.94
2
475-002-0002
Crimp female sockets
25
425-020-5090
TNC Crimp Connector
1
425-400-1223
1.7 EQUIPMENT REQUIRED BUT NOT SUPPLIED
a. Circuit Breaker: 1 ea; 3 amp PULL TYPE REQUIRED for PAR200A
b. Circuit Breaker: 1 ea; 5 amp PULL TYPE REQUIRED for transceiver power (to TY91/92)
c. Headphone Jacks (up to 4 Stereo, as Required)
d. Microphone Jacks (up to 4 as Required)
e. Headphones, 150 (Stereo), up to 4 as required
f. Microphones, up to 4 as required
g. VHF Communication antenna 118-137 MHz, VSWR <2:1 (FAA-TSO approved is recommended)
h. Mounting hardware for TY91, as appropriate
i. Interconnect Wiring, coaxial cable (RG400 or RG142B or equivalent)
1.8 LICENSE REQUIREMENTS
In some localities other than the United States, an Aircraft Radio Station license may be required. In the
United States, you do not need a license to operate a two-way VHF radio aboard aircraft operating domesti-
cally. Aircraft operating domestically do not land in a foreign country or communicate via radio with foreign
ground stations. Flying in international or foreign airspace is permitted, so long as the previous conditions
are met. If you travel to a foreign destination, however, (e.g., Canada, Mexico, Bahamas, British Virgin
Islands) a license is required. Visit http://wireless.fcc.gov for more information.
