Pt Platinum PT-DPSFK - Page 12

12
3 Slide the metal rods (thick ends towards the center) through the loops on the inside of the softbox.
4 Slide the ends of the metal rods into the holes on the mounting bracket.
Note: Leave the softbox rotation knob loose so you can rotate the softbox after it is installed.
Thick end
of the rod
Softbox rotation knob
Mounting holes
